Visit HERMEQ USAWeatherproof Double IBC Spill Pallet
Frequently Bought Together
Covered IBC spill pallet (IBC bund) for two 1000 litre IBCs stored outdoors. A polyethylene sump and steel-framed rain cover help keep rainwater out, so the sump volume stays free for leaks and drips. Standard has a 1140 litre sump and tie-back front openings. Premium has a 1130 litre sump and a roll-up door.
Quickest Available Delivery: Quickest Available Delivery: 5 Day Delivery
The Weatherproof Double IBC Spill Pallet is a covered IBC bund for two 1000 litre IBCs of oils, lubricants and compatible industrial liquids stored outdoors. A polyethylene sump collects leaks, drips and dispensing spills. The steel-framed polyethylene rain cover helps keep rainwater out of the sump, so its volume stays available for containment.
It comes in two configurations, Standard and Premium, which differ in sump capacity, footprint, cover construction and the way you reach the IBC taps.
- Sump capacity: 1140 litres (Standard) or 1130 litres (Premium), both above 110% of one 1000 litre IBC
- Standard size: 2560 x 1350 x 2140mm
- Premium size: 2480 x 1480 x 2300mm
- Standard access: tie-back front openings and removable grids
- Premium access: roll-up door, plus a platform with hand inserts and openings for inspection and pump insertion
Standard configuration
The Standard has a recycled polyethylene sump and a flexible weatherproof polyethylene cover on a steel support frame. The front opens with tie-back flaps, giving access to the IBC taps and dispensing points. The removable grids lift out so the sump can be inspected and cleaned. It is rated for a 3000kg uniformly distributed load (UDL) and is forklift compatible.
Premium configuration
The Premium has a heavy-duty steel frame carrying a thicker cover. The roll-up door gives access to the IBCs without removing the cover. Its polyethylene is recyclable, chemical-resistant and UV-stabilised. The platform has hand inserts and openings for inspection and pump insertion, and a central support must always be used when the platforms are fitted. It suits most forklifts and pallet trucks, although fork extensions may be needed. It also accepts an overflow tray.
Choosing between them
Access is the main difference. The Standard uses tie-back flaps and removable grids. The Premium uses a roll-up door and a platform with pump openings. Compared with the Standard, the Premium is 80mm shorter but 130mm wider and 160mm taller, so check overhead clearance and the space available on the base.
Before you buy
Check the chemical compatibility of the liquid, the filled weight of two IBCs against the ground and your handling equipment, and the footprint of your IBCs. Empty the pallet before moving it. A spill kit for oil and fuel kept beside the bund covers drips at the taps.
Typical uses include construction site compounds, maintenance yards, depots and factory yards storing oils, lubricants, AdBlue and compatible liquids in IBCs outdoors.
Need any help? Contact HERMEQ Today.
Contact our team via email sales@hermeq.nl or use our live chat feature between 8:00am & 17:00pm for help discovering our range.
| Specification | Standard | Premium |
|---|---|---|
| Product type | Covered double IBC spill pallet | Covered double IBC spill pallet |
| IBC capacity | 2 x 1000 litre IBCs | 2 IBCs |
| Sump capacity | 1140 litres | 1130 litres |
| Length | 2560mm | 2480mm |
| Width | 1350mm | 1480mm |
| Height | 2140mm | 2300mm |
| Unit weight | 181kg | 140kg |
| Uniformly distributed load (UDL) | 3000kg | Not stated |
| Sump material | Recycled polyethylene | Recyclable, chemical-resistant, UV-stabilised polyethylene |
| Cover | Flexible weatherproof polyethylene cover | Thick weatherproof cover |
| Cover support | Steel support frame | Heavy-duty steel frame |
| Front access | Tie-back front openings | Roll-up door |
| Platform | Removable grids | Platform with hand inserts and inspection and pump openings |
| Platform support | Not applicable | Central support required when platforms are fitted |
| Overflow tray | Not stated | Accepts an overflow tray |
| Handling | Forklift compatible | Most forklifts and pallet trucks; extensions may be required |
| Application | Outdoor IBC spill containment | Outdoor IBC spill containment |
Is the sump big enough for two IBCs?
Both sumps hold more than 110% of one 1000 litre IBC (1100 litres): 1140 litres for the Standard and 1130 litres for the Premium. In England, the Control of Pollution (Oil Storage) (England) Regulations 2001 require secondary containment of at least 110% of the largest container or 25% of the total stored, whichever is greater. Check the requirements for your site and liquid before relying on any bund.
How do I reach the IBC taps with the cover fitted?
On the Standard, the tie-back front openings are rolled back and secured. On the Premium, the roll-up door opens without removing the cover, and the platform has openings for inspection and pump insertion. A central support must always be used when the Premium platforms are fitted.
Will rain still get into the sump, and how is it cleaned?
The cover helps keep rainwater out, but it is not a sealed enclosure, so inspect the sump regularly and remove any water. On the Standard, lift out the removable grids to reach the sump. On the Premium, use the inspection openings in the platform.
Can I move it with a forklift or pallet truck?
The Standard is forklift compatible. The Premium suits most forklifts and pallet trucks, and fork extensions may be needed. Remove the IBCs and empty the sump before moving either version, and check that your equipment suits the unit.
What can I store on it?
It is intended for oils, lubricants and compatible industrial liquids. Check the chemical compatibility of the specific liquid with the polyethylene before use. Chemical resistance is stated for the Premium only. Do not store flammable or aggressive liquids without confirming suitability.
